Functional Features：

---

The JB-JT-DK694 centralized fire extinguishing control cabinet is a dual platform structure, consisting of a fire extinguishing controller, a hard disk video recorder, a 19 "LCD display, a fire power supply, a UPS uninterruptible power supply, and a battery pack. Chinese LCD display with printing function. Equipped with 1 channel of sound and light output control; 1 set of pump start control output, operation feedback, and fault feedback; 5 sets of valve power control outputs, with a disconnection detection function for the startup output. Form a network with up to 63 on-site manual operation panels via RS485 bus. Equipped with an uninterruptible power supply (UPS) and a matching battery pack, the UPS model and battery pack capacity can be selected according to the number of devices carried, meeting the power supply needs of both local and on-site equipment. Equipped with a hard disk recorder (optional number of video inputs) and a 19 "LCD display. Equipped with one 2U24V/10A linked power supply.

Technical Parameter：

---

Working voltage: AC187V~AC242V (powered by UPS)

Dimensions: 1315mm × 1066mm × 640mm

Usage environment：

---

Temperature: 4 ℃~50 ℃

Relative humidity: ≤ 95%, no condensation
