Functional Features：

---

1. Monitor one single-phase voltage signal and one single-phase current signal, and upload them to

Monitor or monitoring extension;

2. Loop bus power supply, centrally and uninterruptedly supplied by the system host;

3. Encode the address, with each sensor having a unique address code;

4. LCD displays electrical parameters such as voltage.

Technical Parameter：

---

Power supply voltage: DC24V;

Rated power: ＜ 1W;

Alarm display: LED indication;

Communication line requirements: NH-RVSP-2x2.5m ㎡;

Protection level: IP30;

Altitude:<4500m;

Dimensions: 120mmx95mmx65mm;

Installation method: 35mm standard guide rail installation.

Usage environment：

---

Temperature: -10 ℃~50 ℃

Relative humidity: ≤ 95% RH (40 ℃± 2 ℃)
