Functional Features：

---

• Adopting a 192 × 64 dot matrix LCD display - clear, intuitive, and easy to operate;

• Three level programming password protection, suitable for operations by personnel of different management levels;

• Grounding fault detection, warning of faults caused by system grounding;

• 1024 alarm event records and 1024 other event records, real-time recording of system status events for easy querying;

• Real time operation prompts and the ability to display geographic location information for easy operation and management;

• Up to 2 bus circuits can be carried, with a total of 510 addressing points;

• Automatic login function for circuit components, intelligent and fast online deployment of circuit components;

• The controller comes with two sets of passive output contacts (fault contacts and fire alarm contacts).

Technical Parameter：

---

DC backup power: DC24V 7Ah

Main AC power: AC187V~242V 50Hz

Output current/voltage: 2A/24V

Static power consumption: 20W

Maximum operating current: 1.5A (AC 220V)

Usage environment：

---

Environmental temperature: 0 ℃~40 ℃

Relative humidity: ≤ 95% (40 ℃)
